Siemens GGD221.1U 2-Position Fire & Smoke Damper / Actuator Used
Siemens Damper / Actuator
Manufacturer
Siemens
GIBUYS Item No
12627
Availability
In stock
Only 1 left
$150.00
Buy with confidence
All of our products carry a 100% satisfaction guarantee.
We offer a 30-day return policy on everything we sell unless otherwise noted. We care about our customers and we strive for 100% satisfaction with every order.
Product Description
Siemens Fire & Smoke Damper / Actuator
- Brand: Siemens
- Quantity: 1
- Condition: Used, includes all and only what is shown in the images
- Model#: GGD221.1U
- Power Consumption: Running: 150 VA; Holding: 10 VA
- Running Torque: 142 lb-in (16 Nm)
- Minimum Stall Torque: 50 lb-in (39 Nm)
- Torque Reduction at Elevated Temperature: Less than 10%
- Runtime for 90° Operating with Motor at 60 Hz: 15 seconds nominal
- Closing (On Power Loss) with Spring Return: 15 seconds maximum
- Manual Override: Yes
- Auxiliary Switch: 2-SPST, 24VDC, 24VAC to 250VAC, 6A resistive, 2 FLA/LRA (optional)
- Shaft Diameter: 3/8" to 1" (8 to 2.56 cm)
- Minimum Shaft Length: 0.75" (2.0 cm)
- Enclosure Rating: NEMA 1
- Housing Material: Die cast aluminum alloy
- Operating Temperature: 0° to 130°F (-18° to 55°C); One time 350°F (177°C) for 1/2 hour (per UL555S)
- Storage Temperature: -25° to 158°F (-32° to 70°C)
- Humidity: Maximum 95% RH non-condensing
- Pre-Cabled Connection: 18 AWG
Location: Belgium, WI 53004
