SEL SEL-700GT Intertie Protection Relay 0700GT1ABA3A75850221 F/W 700GR301-V4 New

Schweitzer Engineering Laboratories Intertie Protection Relay.

This is a new, ready-to-use protection relay. Includes product literature on CD, factory test paperwork, and mounting hardware.

    Brand: Schweitzer Engineering Laboratories
    Quantity: 1
    Condition: Used
    MFG Part#: 700G#N65T
    Firm Rev: 700GR301-V4
    Spec#: N
    Model#: 0700GT1ABA3A75850221
    Power Supply Voltage: 110-250VDC, 110-240VAC, 50/60Hz
    Power Consumption: 50VA/25W
    Internal Fuse: T3.15A H 250V
    Phase / Neutral Current (Nominal): 5A/5A
    Phase Voltage: 300 VAC Max.
    Phase Current (Nom): 5A
    Phase/VS Voltage (Max): 300V/300VAC
    Control Voltage: 125VDC
    General Purpose Contact Outputs: 250VAC, 30VDC, 6A Resistive
    Pilot Duty: B300
    Ambient Temperature Range: -20°C to +50°C
    Protocols: SEL ASCII, Compressed ASCII, Fast Meter, Fast Operate, Fast Message, Fast SER, Mirrored Bits communications, and Modbus RTU
