Rosemount 3051CA2A22A1AS0B4I5M5 Absolute Pressure Transmitter 0 to 150 psia Used
Rosemount Absolute Pressure Transmitter
Buy with confidence
All of our products carry a 100% satisfaction guarantee.
This is a used Rosemount Absolute Pressure Transmitter. Save thousands and buy used from Green Industrial today!
Max. W.P.: 150 PSI / 10.3 BARA
Supply: 10.5 - 55 VDC
Cal.: 0 to 150 PSI A
Complete Model: 3051CA2A22A1ASOB4I5M5
Model: 3051CA
Pressure Range: 0 to 150 psia/1.5 psia (0 to 10,3 bar/0,1 bar)
Output: 4-20mA with Digital Signal Based on HART Protocol
Materials of Construction
Process Flange Type: Coplanar
Flange Material: SST
Drain/Vent: SST
Isolating Diaphragm: 316L SST
O-ring: Glass-filled TFE
Fill Fluid: Silicone
Housing Material: Polyurethane-covered Aluminum
Conduit Entry Size: 1/2- 14 NPT
Optional All Welded Diaphragm Seal Systems: One Diaphragm Seal, All-Welded System (Direction Mount Connection Type)
Mounting Bracket Options: Coplanar Flange Bracket for 2-in. Pipe or Panel Mounting, all SST
Product Certification Options: FM Non-incendive and Intrinsic Safety Approval
LCD Display: LCD display for Aluminum Housing (Housing Codes A, B, C, and D only)
