Novotechnik LWH 300 Position Transducer Art.024312 F.Nr.042923/D

This is a used Novotechnik Position Transducer. Save thousands and buy used from Green Industrial today!

Manufacturer: Novotechnik

Part Number: LWH 300

Connection: 4 Pin Connector

Electr. Measuring Range: 304 mm

Defined Electrical Range: 300 mm

Output Signal: Voltage Divider

Resistance Value: 5 Ohms

Resistance Tolerance: +/- 20%

Independent Linearity: 0.06 +/- %FS

Repeatability: ≤ ±0.01 mm

Recommended operating wiper current: ≤ 1 μA

Max. wiper current in case of malfunction: 10 mA

Max. permissible supply voltage Ub: 42 VDC

effective temp. coefficient of the output-to-applied voltage ratio: typ. 5 ppm/K

Insulation resistance (500 VDC): ≥ 10 MΩ

Dielectric strength (500 VAC, 50 Hz): ≤ 100 μA
