HEIM LS24 HEIM Spherical Bearing 1.5in Bore 3.25in OD 1.25in W New
Heim USA Heim Spherical Bearing
GIBUYS Item No
B04163
Availability
In stock
Only 2 left
$375.00
Buy with confidence
All of our products carry a 100% satisfaction guarantee.
We offer a 30-day return policy on everything we sell unless otherwise noted. We care about our customers and we strive for 100% satisfaction with every order.
Product Description
Heim USA Heim Spherical Bearing
Material: 52100 Bearing Quality Steel
Ball Material: 52100 Alloy Steel
Liner: Brass
Outside Ring Material: Carbon Steel
Performance: Clevis Applications, Pivot Points
Operating Temp Range: -30° to 300°F
Static Radial Load: 435.926 kN, 98000 lbf
Axial Static Load Rating: 119.537 kN, 26873 lbf
Bore: 1.5 in
Outside Diameter: 3.25 in
Housing Width: 1.25 in
Ball Diameter: 2.5 in
Inside Ring Width: 1.5 in
Misalignment Angle: 5°
Housing Bore Size: 3.25 in
