Flowserve 520MD-02-W1DEE-0000-GM2 Actuated Control Valve 1" 150 Class Used
Flowserve Actuated Control Valve
Manufacturer
Flowserve
GIBUYS Item No
11285
Availability
In stock
Only 2 left
$1,000.00
Buy with confidence
All of our products carry a 100% satisfaction guarantee.
We offer a 30-day return policy on everything we sell unless otherwise noted. We care about our customers and we strive for 100% satisfaction with every order.
Product Description
This is a used Flowserve Actuated Control Valve. Save thousands and buy used from Green Industrial today!
Model: 520MD-02-W1DEE-0000-GM2
Logix 500MD Series: Basic
Type: Flowtop
Size: 1"
Class: 150
Seat Ø: .472A
Cv: 4.6
Characteristic: MOD=%
Mat. Body: CF8M
Trim: 316/PTFE
Stroke: 20 mm
Actuator Type: 127A 15-35 psi
Air Supply: 60 psi min., 90 psi min.
Spring Range: 15-35 psi, 90 psi max allowable.
Failure Condition: close
Δp Actuator: 18.570 psi
Pneumatic Regulator Information
Manufacturer: 138114.999.000
Inlet: 250 PSIG, 17 Bar Max.
Outlet: 150 PSIG, 10.3 Bar Max.
Temp: 175°F, 80°C Max.
