Dodge 6P14H3391/FD145CG16A25 Geared Motor 2HP 1725 RPM In 70 RPM Out 25:0 Ratio New NIB

This is a new Baldor/Dodge Geared Motor. Save thousands and buy from Green Industrial today!

Motor Information

Manufacturer: Baldor Reliance

Cat. No.: 6P14H3391

Spec.: 35W701-0872G1

HP: 2

Volts: 208-230/460

Amps: 6.5 - 6.2/3.1

RPM: 1725

Frame: 145YZ

Hertz: 60

Phase: 3

Service Factor: 1.15

Code: K

Design Letter: B

Class: F

NEMA Nom. Eff.: 82.5%

Performance Factor: 77%

Rating: 40C AMB-CONT

CC: USABLE AT 208V 6.5A

ODE Bearing: 6203

Enclosure: TEFC

Shaft Diameter: 1.1545"

Shaft Length: 2.5"

Keyway Width: 0.2685"

Keyway Length: 1.7130"

Gearbox Information

Manufacturer: Dodge

ID No.: 4502486423001HN6P14H3391

Size: FD145CG16A25

MTG POS: KT

Ratio: 25

Input RPM: 1725

Output RPM: 70

S.F. CRAGMA CL: J

Input: 2
