ABB SACE E2.2V-A Circuit Breaker 1200 A 635V SACE Ekip Touch LSI 1200A New
ABB SACE Circuit Breaker
We offer a variety of finance programs including no payment for 90 days and a cash loan to any equipment financing. CIT is our trusted partner for your financing needs.
Buy with confidence
All of our products carry a 100% satisfaction guarantee.
This is a new ABB SACE Circuit Breaker. Save thousands and buy from Green Industrial today!
Type: SACE E2.2V-A
Rated Current: 1200 A
Rated Max. Voltage: 635 VAC
Rated Short-Circuit: 100 kA
Short Time: 85 kA
Standards: ANSI C37.13 - UL1066
Frequency: 50 - 60 Hz
Order Code: Z2VDUHDE000ADAA020XX
Emax 2 Prefix: (Z) Standard AC Version
Frame: (2) 3p
Short Circuit Rating / Version: (V) 85/100 UL kA @ 635V AC
Frame Rating: (D) UL 1200
UL Rating Plug: (UH) 1200 A
Fixed/Drawout and Terminal connections: (D) Vert. Rear
Ekip Trip Unit: (E) Touch
Protection Functions: Long Time, Short Time, Instantaneous
Auxiliary Power Supply (Ekip Supply) and Measuring Package: (0) None
Communication Modules: (0) None
Redundant Communications and Additional Ekip Modules: (0) None
Auxiliary Contacts (AUX) and Additional Signaling (4K): (A) 4 AUX (4Q) 400V(3)
Remote Reset (YR), 2nd Bell Alarm (S51/2) and Ready to Close Contacts (RTC): (D) RTC 24 VDC
Closing Coil (YC) and Redundant Closing Coil (YC2): (A) 24V AC/DC
Opening Coil (YO): (A) 24V AC/DC
Undervoltage Release (UVR) or Redundant Opening Coil (YO2): (0) None
Spring Charging Motor (M) and Ekip Com Actuator: (2) M with standard aux. for status indication of springs; 24-30V AC/DC
Push Button Locking Options: (0) None
Racking Lock Options (1st lock) and Factory Test Report: (X) None
2nd Racking Lock Options, Mechanical Operations Counter (MOC) and Extended Warranty's: (X) None
